Pick & Place
 |
Used Machine Details: |
Item #: |
Image: |
|
Europlacer Fine Pitch and Chip Shooter Pkg.
Just in and Inspected! |
EP928 and
EP600. EP 928, S/N 0696640, new 1996, 22,946 hours on, 3,540
hours running. 208v EP 600 S/N 0696402, New 1996, 23,453 hours
on, 3,768 hours running. 220v -3 Intelligent Feeder Trolley?s
(up to 33 8mm feeders)
*Feeder
Elements for intelligent trolley - 8 mm feeder elements
-57 standard -16 for 040 - 40 tape reels - 12mm feeder
elements - 19 standard - 10 tape reels - 16mm feeder elements
- 6 standard -3 tape reels - 24mm -5 standard -4 tape
reels -3 Programmable Tape Feeder Trolley?s
*Programmable
Tape Feeders - 4 32mm feeders - 4 44mm feeders - 4 56mm
feeders -2 Intelligent Vibratory Stick Feeders -1 Set-Up
Station for programmable tape feeders -1 micro-terminal for
programming feeders (includes base, power supply, and bar code
reader pen) -1 intelligent matrix tray feeder (mounts inside EP
600) -1 placement calibration plate used on both EP 600 and Ep
928 machines (includes calibration chips and nozzles)
-1 set of technical documentation
 |
SM3678 |
|
|
Quad
4C Pick & Place Machines
Just in and Inspected! |
Quad IVc
Pick & Place.
S/N
Hours
Year
Quad
4C 2487 5246 ? Conveyor
Quad
4C 2751 18927 1996 No Conveyor
Quad
4C 3394 11633 1996 No Conveyor
Quad
4C 2155 8437 ? No Conveyor
Quad 2C
3162 7261 1997 No Conveyor
All
machines come with 20 assorted 8 & 12mm feeders and 2 vibratory
bases. 16, 24 and 32mm feeders available.
|
SM3670 |
|
|
Universal GSM-1
SMT Assembly Machine |
GSM-1 machine
with tray feeder and many feeders and one feeder cart
This machine comes with 2
upward cameras, 10 44mm, 10 32mm, 5 25m, 1 vibratory
and 1 belt feeders, 1 feeder cart with 3 feeder bases and 2
upward looking cameras.
S/N 4689A
079640-6-4642520 230 volt, 3 phase 30 A, 50/60 Hz.
26,000,000 cycles on counter
|
SM3666 |
Coming soon |
|
Contact
Systems 3S-80 Pick & Place machine
|
Contact
System's Model 3S-80 Pick and Place Handling system is state
of the art and ready for usage. Holds a total of
80, 8mm feeders. Feeders sold separately. Complete with
computer, monitor, software and manuals.
- View Image 2:
Contact Systems 3S-80 Pick
& Place machine
- View Image 3:
Contact Systems 3S-80 Pick
& Place machine
- View Image 4:
Contact Systems 3S-80 Pick
& Place machine
- View Image 5:
Contact Systems 3S-80 Pick
& Place machine |
SM3630 |
 |
Philips CSM Eclipse
|
The CSM Eclipse
is a high-performance machine capable of placing 0402 up to
fine pitch QFPS, all in a machine with a foot print of 1.65
x 1.30m (5.4 x 4.3ft). This machine has two Z-programmable
heads allow a placement rate of up to 5000 SMDs per hour.
The CSM Eclipse is equipped with laser alignment, upward looking
cameras, automatic nozzle changer, uses tape, stick and tray
component feeders, conveyer width auto adjust. This system
can place and align rectangular SMDs like 0402 chips resistors,
PLCCs, SO and ICs.
Model: Eclipse, Type: PA130800, S/N: 946601308001
- View Image 2: Philips/Assembleon
Eclipse
- View Philips factory Specs:
Philips CSM
Eclipse Specifications
|
SM3593 |
 |
Robodyne ELIM 150
|
Robodyne ELIM Robotic
workcell placement w/vision. Pick and place for odd from parts.
Power-200-240 VAC 50-60 Cycle 10 AMPS single phase. Air: 75-120
PSI @ 5.0 SCFM, Approximate WT. 1200 Lbs., 544kg
Model: ELIM-150-HH, S/N: 500030, 500031& 500032 |
MI3525 |
 |
Contact
Systems: Contact 3-Series feeders
SOLD
|
|
8mm |
10 |
TF8 |
0 |
|
TF8 13" Reel |
0 |
|
TFS8A |
0 |
|
12mm |
7 |
TF12 13" Reel |
3 |
|
TFS12A |
3 |
|
16mm |
6 |
TF16 |
1 |
|
TFS16 |
4 |
|
24mm |
5 |
TF24 |
4 |
|
|
TFS24 |
1 |
|
|
|
Vibratory Feeder
Lanes
SOLD
|
|
Vib plates |
13 |
300-9-C, 300-01, 300-1, 300-09-P, 300-05-P,
300-16-C, 300-17-C, 300-5-C, 300.2,
300-15-C, 300-05-P, 300-02-MOD, 300-1-C |
|
|
|
Vibratory feeder
Accessories
SOLD
|
| Accessory: |
Description &
Qty: |
| Vibratory feeder lanes |
300.2 (SOLIC, PLCC-2C, PLCC-20, SOIC)
300-01 (SOIC-14/16)
300-1 (SOIC-14/16)
300-09-P (PLCC-28/32)
300-05-P (SOIC-16/20)
300-16-C (SOIC-8)
300-17-C (PLCC-52)
300-5-C (SOIC)
300-9-C (PLCC-28/32)
300-15-C (PLCC-44)
300-05-P (SOIC-16/20)
300-02-MOD (SOLIC, PLCC-20, SOIC 14/16/8)
300-1-C (SOIC-14/16) |
|
N/A |
|
Assembleon Eclipse
Pick & Place Machine
SOLD
|
This
machine was refurbished by Assembleon and is still in the
crate. Includes tray handler. The CSM Eclipse is a high-performance
machine capable of placing 0402 up to fine pitch QFPS, all
in a machine with a foot print of 1.65 x 1.30m (5.4 x 4.3ft).
This machine has two Z-programmable heads that allow a placement
rate of up to 5000 SMDs per hour. The CSM Eclipse is equipped
with laser alignment, upward looking cameras, automatic nozzle
changer, uses tape, stick and tray component feeders, conveyer
width auto adjust. This system can place and align rectangular
SMDs like 0402 chips resistors, PLCCs, SO and ICs. There are
no feeders with this machine. 200-240 volt, 3 phase, S/N 946601308001
- View Image 2: Assembleon
Eclipse Pick & Place
- View Image 3: Assembleon
Eclipse Pick & Place
- View Image 4: Assembleon
Eclipse Pick & Place |
SM3615 |
 |
|
|
4
machine available. 2 stand alone and 2 with conveyors. All
checked out and ready to go. Lots of feeders available.
- View Image 2: Quad
4C Pick & Place Machine
- View Image 3: Quad
4C Pick & Place Machine
- View Image 4: Quad
4C Pick & Place Machine
- View Image 5: Quad
4C Pick & Place Machine
- View Image 6: Quad
4C Pick & Place Machine
- View Image 7: Quad
4C Pick & Place Machine
- View Image 8: Quad
4C Pick & Place Machine
- View Image 9: Quad
4C Pick & Place Machine |
SM3620 |
|
Juki KE-2050L Pick
& Place Machine
SOLD |
Machine
has 20, 8mm feeders and a trolley retrofit kit. Less than
a year old and over 2 years left on warranty.
- View: Juki Website: Juki
KE-2050L Pick & Place Machine |
SM3616 |
|
Quad QSA-30A(V)
High Speed Pick -N- Place Machine
SOLD |
Three head, 13,000
component per hour machine with upward/downward vision, tray
holder, 10 reel feeders, 1 vibratory feeder, 3050 hours on
time, 883 hours run time. Software and manuals. Software:
MMI ver. 6.75; VME ver. 2.612; Vision MM 6.450; Vision VME
OX10.V10; Electrical Information: 120 volt, 1phase.
Model: OSA30, S/N: C8-0117-H2, Vintage: 2000
- View Image 2: Quad
QSA30V Pick & Place Machine
- View Image 3: Quad
QSA30V Pick & Place Machine
- View Image 4: Quad
QSA30V Pick & Place Machine
- View Image 5: Quad
QSA30V Pick & Place Machine
- View Image 6: Quad
QSA30V Pick & Place Machine
- View: Quad factory Specs:
Quad QSA 30 Specifications. |
SM3605A |
|
| Panasonic Soft Beam Selective
Soldering System
SOLD |
Panasonic SoftBeam automated
white-light selective soldering machine with Cognex auto-vision
alignment: This selective soldering system uses a focused
light source. The beam can be focused down to a 1mm diameter.
This is a fully automatic and programmable system. Very lightly
used and in excellent condition. This SMT machine is a 2004
model with only 98 hours of use.
Optional Features included:
• Dual shuttle system
• Cognex auto-vision alignment
• Wire-feeding system with
auto-Z compensation
• Variable spot-size optics
system
• Fume Extractor
• Theta motion of head
• Auto-Calibration
Slim-cell Model: yb-04fh1yhp MFD: 043S003
Softbeam controller Model: yb-02AD5, MFD: 043B006
- View/Download: Panasonic
Selective Soldering factory Specifications (pdf, 1.58mb)
slim-II-cell
(pdf, 796 KB)
softbeam
controller (pdf, 488 KB)
|
SO3518 |
 |
| Philips FCM Base II Modular
Chip Shooter
SOLD
|
Philips FCM
(Fast Component Mounter) Base II - Modular Chip Shooter (Assembleon
Multiflex). Four trolley machine that is capable of 100,000
parts per hour, Applicable Components from 0201 to 25mmx25mm and
a 50x50 (1x1") to 460x390 (18.1x15.4") board size. Manuals,
computer, monitors, four trolleys per machine, and feeders
included. Up to 2 complete systems available. All new in 6/99.
Original discounted cost $750,000 each.
S/N: see below, 6/99
FCM II: DC00716, FCM II: DC00719 -- Each with 78
8mm feeders and 12 12mm feeders.
- View more Assembleon factory
Specifications:
Assembleon Multiflex (FCM II) |
SM3490 |
|
|
Quad 4C MK II Pick & Place Machine
SOLD
|
Quad IVc
Mk-II Pick & Place machine with 18 8mm feeders, 5 12mm feeders
and 1 24mm feeder plus 2 matrix tray feeders. Machine has 1
head, 6 nozzles in automatic nozzle changer, laser fly vision
system with rear CCD vision with stationary camera for large
components and automatic rail width adjustment. Includes
computer and monitors, manuals and software on disks. S/N 2087,
Model 4C MK-2A. This machine is in ?as new? condition.
|
|
 |
